The EII 2.5HP Cyclonic Sanding Portable is designed for demanding dust extraction operations with 1 to 2 technicians using source capture tools at the same time.  The Cyclonic Portable can also be utilized for housekeeping to assist in maintaining a clean shop.

Application:

• 1 Tech Grinder Vacuum System
• 1 to 2 Tech Orbital Sander Vacuum System

Part Numbers:

• SYS-050-18100000:  Compact Cyclonic Portable (5 Gallon Can)
• SYS-050-18000200:  Cyclonic Portable (10 Gallon Can)

Equipment Specs:

• Construction:  Fully welded steel construction
• Finish:  Texture Blue powder coated painted finish
• Blower:  2.5HP Brush Motor (4000 Hrs Intermittent Duty)
• Filtration: Cyclonic Separation with Internal Wall Guarding Filter from the Dust Upon Entry (removes 85%+ of the dust).  Secondary Polyester Cartridge Filter (99.93% at 3 microns or larger) and Final HEPA Filter.
• Controls (On/Off/Auto Switch):  3 Position Switch. Auto position will start and stop portable based on if pneumatic tool is in operation
• Electrical: 115 Volt 1Ph 60Hz, 13.9 amp, 1512 Watt (US / Canada).  Includes 15′ (4.55M) Electrical Cord
• Adjustable Vacuum Performance: Manual Speed Dial
• Inlets:  Qty 2: 1-1/2″ Inlets
• Dimensions:  24″W x 18″D x 41″H

System Performance:

• Vacuum – 113.4″WC
• Flow – 115.7 CFM

Includes:

• Qty 2 – 1-1/4″ to 1” x 20′ Hoses w/ Airline
• Qty 2 – Hose Hangers

Optional Additions:

• 1-1/4” Hoses w/ Airline (For Grinding Application)
• 1-1/4” to ¾”” Hoses w/ Airline (For Lightweight User Friendly Sanding)
• Manual Reverse Pulse Filter Cleaning (UPG-050-18PB0000)
• Top Mount Primary Storage Tray (SYS-050-18100SR1)
• Top Mount Second Level Storage Tray (SYS-050-18100SR2)
• Qty 3 – Back Storage Racks (SYS-050-18100SR3)
• Accessory Cart w/ 4.5 Gallon Garbage Pail, Qty 10 – Peg Board Hooks & Lockable Cabinet Door (POR-P25-B01A0005)
• 2.5HP Brushless Motor (20,000 Hrs Continuous Use) – 20 Amp Circuit Required.  Vacuum – 105″WC / Flow – 120 CFM  (SYS-050-18000211)
• Magnahelic gauge (Indicates when pressure differential is too high and filters need replacement) (HAR-BAK-MAGKIT0P)
